MMS FLEX: FCA Marelli 11GF

Bench Solution for FCA Marelli 11GF

Release 7.48.0.0 of Flex allows you to Bench program FCA engine control units equipped on mild hybrid systems, extending intervention possibilities on a more modern range of vehicles.

With protocol for Marelli 11GF you can perform engine calibration operations in order to improve performance, as well as restore and clone ECUs without the need to open the unit.

It’s super easy: read the full backup of the damaged unit and transfer data to a working unit. No need to have both vehicles inside the workshop.

FCA Marelli 11GF TC277 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Some of the supported vehicles:

  • Fiat 500 (332) 1.0L FireFly MHEV 68HP
  • Fiat Panda (312) 1.0L FireFly MHEV 68HP
  • Lancia Ypsilon (846) 1.0L FireFly MHEV 68HP

This new protocol is available for the following software packages:

  • FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
  • FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
  • FLS0.5M – SW Flex Full Master
  • FLS0.5S – SW Flex Full Slave
  • FLS0.10M – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Master
  • FLS0.10S – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Slave



Posted on by

MMS FLEX: Ford UTCU3

Fomoco UTCU3 TCUs Now Covered

New version 7.47.0.0 of Flex out now, introducing a new protocol dedicated to Fomoco UTCU3 TCUs installed on Ford vehicles with 6, 8, and 10-speed automatic transmissions.

With the new Flex release, you can perform OBD programming of a wide range of vehicles that are equipped with this control unit, by connecting directly to the diagnostic port.

Operating in OBD means getting quick access to the map area, making it possible to carry out necessary modifications to optimize transmission performance.

Ford Fomoco UTCU3 TC277 Read/Write/Checksum Calculation Maps

Some of the supported vehicles:

  • Ford Bronco (VI) (2020MY) 2.7L Ecoboost V6 335PS

  • Ford Kuga (III) (2020MY) 1.5L EcoBoost 150PS

  • Ford Ranger T6 (2019MY) 2.3L Ecoboost 270PS

This new protocol is available for the following software packages:

  • FLS0.2M – SW Flex TCU OBD/Bench Master
  • FLS0.2S – SW Flex TCU OBD/Bench Slave
  • FLS0.5M – SW Flex Full Master
  • FLS0.5S – SW Flex Full Slave



Posted on by

KESS3: Ford Conti EMS2910 EMS2916 OBD

OBD protocol for Ford Conti EMS2910 EMS2916

Thanks to this development, it is now possible to work via OBD on the latest Ford and Lincoln vehicles for the US and global markets, equipped with 1.0, 1.5, 2.0 and 2.0 EcoBoost engines and Continental EMS2910, EMS2916 ECUs.

Today, KESS3 allows direct access through the diagnostic port on these applications from 2023 onwards, offering fast and reliable access to a modern platform designed to advancedly manage combustion strategies, turbocharging and emissions control.

A concrete opportunity for workshops working on next-generation vehicles: a smooth, safe procedure perfectly integrated into daily operations.

Technical focus

  • Connection: OBD

  • ECU: Continental EMS2910 / EMS2916

  • Production years: from 2023

  • Brands involved: Ford, Lincoln

Supported vehicles

  • Ford Bronco Sport, Escape, Kuga, Maverick, Mustang S650, Puma, Transit Courier

  • Lincoln Corsair, Nautilus

Shop KESS3 Now
Posted on by

CMDFlash v3.2.0.278 – Ford EMS2910/EMS2916 + UTCU4

OBD:

Ford VITESCO EMS2910/16 FULL OBD (for Ford 1.0,1.5,2.0,2.3 EcoBoost engines ) VR/R/W/CHK/Recovery
This new OBD protocol allow you to manage the map and firmware areas of VITESCO EMS2910/16 ECUs.
The solution operates directly through the diagnostic port.

Ford-VW Continental SID213 FULL OBD VR/R/W/CHK/Recovery
Reworked: added OBD Real Read functionality

Ford TEMIC UTCU4 TC387 FULL OBD VR/R/W/CHK/Recovery
This new OBD protocol allow you to manage the map and firmware areas of TEMIC UTCU4 TC387 TCUs.
The solution operates directly through the diagnostic port.

OBD + BENCH OBD UNLOCK:

OPEL DELCO E90/E93 VR/R/W/CHK/Recovery

More info and pricing
Posted on by

MMS FLEX: OBD Mode for EMS2910 / EMS2916

EMS2910 / EMS2916 OBD Released!

New protocol released in version 7.44.0.0 of Flex out now for Vitesco EMS2910 and EMS2916 engine units installed on new generation Ford vehicles.

This new protocol allows programming operations on vehicles with 2.0L EcoBoost, 2.3L EcoBoost, and 1.0L MHEV engines.

Access the map zone via OBD and make your modifications directly via the diagnostic port, safely and quickly: no need to open or ship the unit to our labs.

New Protocols:

  • Ford Vitesco EMS2910 TC387 Read/Write/Checksum Calculation Maps and ASW
  • Ford Vitesco EMS2916 TC387 Read/Write/Checksum Calculation Maps and ASW

Some of the supported vehicles:

  • Ford Mustang (VII-S650) 2.3L EcoBoost 100PS
  • Ford Bronco (VI) 2.0L EcoBoost 250PS
  • Ford Puma (I) 1.0L EcoBoost MHEV 140PS

This new protocol is available for the following software packages:

  • FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
  • FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
  • FLS0.5M – SW Flex Full Master
  • FLS0.5S – SW Flex Full Slave



Posted on by

MMS FLEX: OBD Mode for SID213 and SID213EVO

SID213 / SID213 EVO OBD Programming!

New protocol released in version 7.43.0.0 of Flex for Conti SID213 and SID213EVO engine units installed on new gen Ford and Volkswagen vehicles.

This new solution is made to work on vehicles with 2.0L EcoBlue and 2.0L TDI engines.

A new protocol that opens access to the map area via OBD connection, therefore you can now make your modifications via the diagnostic port, safely and quickly: no need to open the unit or ship it to our labs.

New Protocols:

  • Ford/VW Continental SID213 TC387 Read/Write/Checksum Calculation Maps
  • Ford/VW Continental SID213EVO TC387 Read/Write/Checksum Calculation Maps

Some of the supported vehicles:

  • Ford Ranger WildTrak (IV) 2.0L 16v EcoBlue 205PS+
  • Volkswagen Amarok 2.0L TDI

This new protocol is available for the following software packages:

  • FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
  • FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
  • FLS0.5M – SW Flex Full Master
  • FLS0.5S – SW Flex Full Slave



Posted on by

bFlash Update V2112A

This new update covers the EMS2208 control units that can be found in some of the Lincoln & Ford Models.

It is possible to read and write these control units by OBD.

Q&A

How do I connect to the control unit?
You can connect bFlash directly to the OBD socket.

How fast is it?
Reading is done in approximately 2 minutes and 30 seconds.
Writing time is around 1 minute.

What control units are included in this bFlash update?
You can find the full list of control units list below.

New OBD Protocols:

Ford

EMS2208 TC1767

Lincoln

EMS2208 TC1767

Flashing, datalogging & diagnostics.

All in one tool!

Posted on by

BitBox 3.4.3 + New BitEdit Modules

BitEdit NEW Modules:

Isuzu Transtron Aurix – Software module for editing calibrations Transtron ECUs of diesel Isuzu vehicles with 3.0TD 4JJ3 engine. Infineon Aurix MCU supported.

Isuzu Delphi – Software module for editing calibrations of Delphi ECUs for diesel Isuzu vehicles.

BitBox Module Updates:

Ford Bosch MED(G)17 Petrol CAN ready for tests with following families:

  • FID 322: Ford Bosch MED17.0 TC1767 – read/write/checksums calculation
  • FID 323: Ford Bosch MED17.0.1 TC1767 – read/write/checksums calculation
  • FID 324: Ford Bosch MED17.0.7 TC1782 – read/write/checksums calculation
  • FID 325: Ford Bosch MEDG17.0 TC1797 – read/write/checksums calculation

BitBox Fixes and improvements:

  • Added reading/writing mode selection for some families
  • Toyota Denso Gen3 now available several reading options: Read, Virtual read
  • GM Delphi DCM3.7AP now supported more ECU types. Reading available in 2 options: OBD read, Bench read.
  • Totally remade GM ACDelco E98, E87, E83 families. Families become more stable and safe
  • Ford Continental SID209 fixed patching algorithm for some ECU variants
  • BMW Siemens GS20 fixed reading, writing and checksums calculation
  • Continental GPEC4LM now also supported by FID321
  • Various UI improvements and fixes



View Full Range of modules here.

bitbox_logo

Posted on by

Flex 5.20.0.0 – ZF 6HP BENCH!

Bench Solutions for TCU BOSCH ZF-6HPxx

Released new FLEX software for Bench programming/tuning of BOSCH ZF-6HPxx automatic transmission, this is installed on brands like BMW, FORD, LAND ROVER, JAGUAR, just to mention some of them.

With this Flex update (5.20.0.0), it is now possible to service ZF BOSCH 6HP26, 6HP19, 6HP28, 6HP32, 6HP21, and to read & write content of single electronics modules.

Supported Vehicles:

  • BMW (E90)
  • BMW (F30)
  • Jaguar XF (X250, J05, CC9)
  • Land Rover (LR4, T5, LA)
  • Rolls-Royce Phantom VII
  • Maserati Quattroporte Sport GT S 4.2
  • Ford Territory Turbo
  • and many others …

The new protocol BOSCH ZF-6HPxx is available for the following software packs:

  • FLS0.2 – Package Flex TCU OBD/Bench (car, bike, van)
  • FLS0.5 – Package Flex FULL

Time to Read: ~ 50 seconds | Time to Write: ~ 20 seconds

NEW BENCH PROTOCOLS:

  • TCU – ALPINA BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – ASTON MARTIN BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – BENTLEY BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – BMW (Fxx & Exx) BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – FORD BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – HYUNDAI BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – JAGUAR BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – KIA BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – LAND ROVER BOSCH ZF 6HP– Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – LINCOLN BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – ROLLS ROYCE BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – DAVID BROWN BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – WIESMANN BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – MASERATI BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – DAIMLER BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]
  • TCU – MORGAN BOSCH ZF 6HP – Read/Write/Checksum ExtFlash M58BW016-B [2048KB]

Bugfix:

  • Fixed Virtual Reads for DQ250Cxx
  • Fixed Connect error in BDM with SIEMENS SID206

Software Improvements:

  • Added New CRC for Hyundai Denso SH72543
  • Added New Type of Ranger Rover Bosch MEDC17.9 for OBD protocol
  • Added OBD protocol for Toyota Denso 276122-064
  • Added New CRC for Mitsubishi Denso SH72543
